TM 5-3805-294-23-4
0583
WINDSHIELD DISASSEMBLY - Continued
3
13
14
13
HYEX02776
Figure 4. Lock Handle Removal.
2.
Remove two bolts (Figure 5, Item 15), washers (Figure 5, Item 16), and windshield wiper wiring harness (Figure
5, Item 17) from windshield assembly (Figure 5, Item 3). Discard bolts.
