TM 5-3805-294-23-4
FIELD MAINTENANCE
WINDSHIELD ASSEMBLY REPLACEMENT
INITIAL SETUP:
Personnel Required
Tools and Special Tools
Construction Equipment Repairer 91L (2)
Tool Kit, General Mechanic's: Automotive
(Volume 5, WP 0796, Table 2, Item 119)
Gloves, Welders (Volume 5, WP 0796, Table 2,
References
Item 55)
TM 5-3805-294-24P: Fig. 96 (Volume 5,
Goggles, Industrial (Volume 5, WP 0796, Table 2,
WP 0794)
Item 58)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Materials/Parts
Sealing Compound
Equipment Condition
(Volume 5, WP 0797, Table 1, Item 40)
Machine safely parked and shut down
Sealing Compound, Thread Lock
(TM 5-3805-294-10). (Volume 5, WP 0794)
(Volume 5, WP 0797, Table 1, Item 43)
Negative battery cable disconnected. (WP 0521)
Screw (Volume 5, WP 0798, Table 1, Item 82)
Front windshield wiper and motor removed.
Qty: 8
Bolt (Volume 5, WP 0798, Table 1, Item 80)
Qty: 4
Bolt (Volume 5, WP 0798, Table 1, Item 78)
Time to Complete
Qty: 2
3.0 Hour(s)
Bolt (Volume 5, WP 0798, Table 1, Item 62)
Qty: 2
WINDSHIELD ASSEMBLY REMOVAL
WARNING
Replace broken window glass carefully. Wear a pair of heavy leather gloves or other suitable
hand protection. Support window glass during removal and installation, as required, so it does
not drop. Failure to comply may result in serious injury or death to personnel.
NOTE
The parts that are replaced in this procedure will not be found on a HYEX that has the
Supplemental Armor System (SAS) cab installed.
1.
Remove four screws (Figure 1, Item 1) and two covers (Figure 1, Item 2) from windshield assembly (Figure 1,
Item 3). Discard screws.
0583-1
