TM 5-3805-294-23-4
0582
FIELD MAINTENANCE
SOLAR SENSOR REPLACEMENT
INITIAL SETUP:
Tools and Special Tools
Equipment Condition
Tool Kit, General Mechanic's: Automotive (Volume
Machine safely parked and shut down
5, WP 0796, Table 2, Item 119)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Negative battery cable disconnected. (WP 0521)
Personnel Required
Construction Equipment Repairer 91L (1)
Time to Complete
0.2 Hour(s)
References
TM 5-3805-294-24P: Fig. 123 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
1.
Remove solar sensor (Figure 1, Item 1) from cover (Figure 1, Item 2).
0582-1
