TM 5-3805-294-23-4
0581
SEAT STAND INSTALLATION - Continued
9.
Push lever (Figure 26, Item 7) down and move seat stand (Figure 26, Item 6) backwards.
7
6
2
5
4
3
1
HYEX02028
Figure 26.
Seat Stand Cover Installation
10.
Install cover (Figure 26, Item 2) to seat stand (Figure 26, Item 6) with two screws (Figure 26, Item 3),
lockwashers (Figure 26, Item 4), and washers (Figure 26, Item 5).
11.
Install two caps (Figure 26, Item 1) to cover (Figure 26, Item 2).
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Install seat. (WP 0580)
2.
Install seat belt. (WP 0579)
3.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
