TM 5-3805-294-23-4
0579
FIELD MAINTENANCE
SEAT BELT REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
TM 5-3805-294-10 (Volume 5, WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
(Volume 5, WP 0796, Table 2, Item 119)
WP 0794)
Materials/Parts
Tags (Volume 5, WP 0797, Table 1, Item 52)
Equipment Condition
Machine safely parked and shut down
Lockwasher (Volume 5, WP 0798, Table 1, Item
(TM 5-3805-294-10). (Volume 5, WP 0794)
56) Qty: 2
Lockwasher (Volume 5, WP 0798, Table 1, Item
10) Qty: 4
Time to Complete
0.4 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 120 (Volume 5,
WP 0794)
REMOVAL
1.
Move seat forward as far as possible (TM 5-3805-294-10).
2.
Remove two screws (Figure 1, Item 1), lockwashers (Figure 1, Item 2), washers (Figure 1, Item 3), washers
(Figure 1, Item 4), spacers (Figure 1, Item 5), and isolator (Figure 1, Item 6) from bracket (Figure 1, Item 7).
Discard lockwashers.
0579-1
