TM 5-3805-294-23-4
0579
REMOVAL - Continued
7
8
11
12
10
9
HYEX02333
Figure 2.
Left Belt Removal.
4.
Remove bolt (Figure 3, Item 13), lockwasher (Figure 3, Item 14), belt (Figure 3, Item 12), and spacer (Figure
3, Item 15) from bracket (Figure 3, Item 16). Discard lockwasher.
