TM 5-3805-294-23-4
0608
DOOR REMOVAL
NOTE
An assistant will be needed to help support the door during removal.
1.
With the aid of an assistant, remove four nuts (Figure 1, Item 1), lockwashers (Figure 1, Item 2), washers
(Figure 1, Item 3), and door (Figure 1, Item 4) from storage compartment cover (Figure 1, Item 5). Discard
5
1
2
3
6
HYEX00222
4
Figure 1. Storage Compartment Door Removal.
2.
Remove hold open latch (Figure 1, Item 6) from door (Figure 1, Item 4).
END OF TASK
