TM 5-3805-294-23-4
0633
RIGHT SIDE UPPER LINE INSTALLATION - Continued
2.
Install clamp (Figure 5, Item 49) to line (Figure 5, Item 43) with screw (Figure 5, Item 47) and washer (Figure
5, Item 48).
3.
Lightly lubricate O-ring (Figure 5, Item 46) with clean oil.
4.
Install O-ring (Figure 5, Item 46) to line (Figure 5, Item 43).
5.
Install hose (Figure 5, Item 45) to line (Figure 5, Item 43).
6.
Lightly lubricate O-ring (Figure 5, Item 44) with clean oil.
7.
Install O-ring (Figure 5, Item 44) to line (Figure 5, Item 43).
8.
Install hose (Figure 5, Item 36) to line (Figure 5, Item 43).
END OF TASK
RIGHT SIDE LOWER LINE INSTALLATION
WARNING
LUBRICATING OIL
NOTE
Install hoses and position fittings as noted prior to removal.
Install clamps as noted prior to removal.
1.
Install line (Figure 6, Item 32) to boom (Figure 6, Item 20) with three bolts (Figure 6, Item 38), washers (Figure
6, Item 39), clamps (Figure 6, Item 40), flanges (Figure 6, Item 41), and clamps (Figure 6, Item 42).
0633-11
