Figure 8. Left Side Lower Line Installation.
AUXILIARY CIRCUIT HI-FLOW SELECTOR VALVE REPLACEMENT

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  1042    1043    1044    1045    1046  1047  1048    1049    1050    1051    1052
. .
TM 5-3805-294-23-4
0633
LEFT SIDE LOWER LINE INSTALLATION - Continued
2.
Lightly lubricate O-ring (Figure 8, Item 16) with clean oil.
3.
Install O-ring (Figure 8, Item 16) to line (Figure 8, Item 2).
4.
Install hose (Figure 8, Item 15) to line (Figure 8, Item 2).
5.
Lightly lubricate O-ring (Figure 8, Item 13) and O-ring (Figure 8, Item 14) with clean oil.
6.
Install O-ring (Figure 8, Item 13) and O-ring (Figure 8, Item 14) to fitting (Figure 8, Item 12).
7.
Install fitting (Figure 8, Item 12), O-ring (Figure 8, Item 13), and O-ring (Figure 8, Item 14) to line (Figure 8,
Item 2).
8.
Install hose (Figure 8, Item 11) to fitting (Figure 8, Item 12).
9.
Install bolt (Figure 8, Item 6), washer (Figure 8, Item 7), clamp (Figure 8, Item 8), flange (Figure 8, Item 9), and
clamp (Figure 8, Item 10) to line (Figure 8, Item 2).
10.
Lightly lubricate O-ring (Figure 8, Item 5) with clean oil.
11.
Install O-ring (Figure 8, Item 5) to fitting (Figure 8, Item 4).
12.
Install fitting (Figure 8, Item 4) and O-ring (Figure 8, Item 5) to line (Figure 8, Item 2).
13.
Lightly lubricate O-ring (Figure 8, Item 3) with clean oil.
14.
Install O-ring (Figure 8, Item 3) to line (Figure 8, Item 2).
15.
Install hose (Figure 8, Item 1) to line (Figure 8, Item 2).
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Release vacuum from hydraulic reservoir. (WP 0620)
2.
Connect negative battery cable. (WP 0521)
3.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
0633-15/16 blank
