TM 5-3805-294-23-1
0015
Table 1. DTC 94.03 - Low-Pressure Fuel Signal Out of Range High - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Turn key switch to ON position,
6.
Voltage Between
but DO NOT START ENGINE
Engine Interface
(TM 5-3805-294-10). (Volume
Wiring Harness
Connector P03
5, WP 0794)
Sockets 1 and 2
Greater Than 5.5
Volts.
2.
Measure voltage (Volume 3,
WP 0369) between engine
interface wiring harness
connector P03 socket 1 and
socket 2. (Volume 5,
WP 0800, Figure 55) Note
reading.
3.
Turn key switch to OFF
1.
If greater than 5.5 volts,
position (TM 5-3805-294-10).
reconnect all connectors and
discontinue this
(Volume 5, WP 0794)
troubleshooting procedure.
Perform the troubleshooting
procedure for DTC 3510.03 as
though the DTC is active.
2.
If less than 5.5 volts, proceed
to Malfunction 7.
1.
Connect engine interface
7.
Check For DTC
wiring harness connector P03
94.03 With Fuel
to the fuel transfer pump
Transfer Pump
pressure sensor. (Volume 5,
Pressure Sensor
Reconnected.
WP 0800, Figure 55)
2.
Turn key switch to ON position,
but DO NOT START ENGINE
(TM 5-3805-294-10). (Volume
5, WP 0794).
3.
Refresh DTCs. Note if DTC
94.03 is still an active DTC.
(Volume 3, WP 0362)
0015-4
