TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 100.01 - ENGINE OIL PRESSURE SIGNAL EXTREMELY LOW
INITIAL SETUP:
Tools and Special Tools
References (cont.)
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0363
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0410
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0417
(Volume 5, WP 0796, Table 2, Item 2)
Volume 4, WP 0508
Test Set, MSD Electronic Systems
Volume 4, WP 0510
(Volume 5, WP 0796, Table 2, Item 116)
Volume 4, WP 0511
Volume 4, WP 0521
Volume 4, WP 0593
Personnel Required
Volume 5, WP 0800
Construction Equipment Repairer 91L (2)
Equipment Condition
References
Machine safely parked and shut down
TM 5-3805-294-10 (Volume 5, WP 0794)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Test Equipment Setup for MSD and Service
Volume 3, WP 0335
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0362
Troubleshooting Sequence
DTC 100.01
When DTC is Displayed
When the engine is running and the error is active.
Related Information
The ECU senses a lower than expected engine oil pressure.
The engine must be running for the code to be set.
The warning value set point is dependent on engine speed.
1569.31 is set when this code is active and engine has not shutdown.
1110.31 is set if the shutdown feature is enabled.
1109.31 code is set 30 seconds before the ECU shuts down the engine.
Alarm Level
Stop machine operation and shut down engine.
Control Unit Response
Maximum engine power is derated up to 60 percent.
