TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 97.16 - WATER IN FUEL DETECTED
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0345
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0369
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0454
Multimeter, Digital
Volume 4, WP 0509
(Volume 5, WP 0796, Table 2, Item 77)
Volume 4, WP 0511
Probe Set, Standard
Volume 5, WP 0800
(Volume 5, WP 0796, Table 2, Item 91)
Test Set, MSD Electronic Systems
Equipment Condition
(Volume 5, WP 0796, Table 2, Item 116)
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
Personnel Required
Test Equipment Setup for MSD and Service
Construction Equipment Repairer 91L (2)
ADVISOR. (Volume 3, WP 0375)
References
TM 5-3805-294-10 (Volume 5, WP 0794)
Troubleshooting Sequence
DTC 97.04
DTC 97.16
When DTC is Displayed
Whenever the ignition is on and the error is active.
Related Information
The water in fuel voltage drops below the minimum threshold. The voltage is lower than what is physically possible
for the water in fuel sensor to achieve.
Alarm Level
Warning.
Control Unit Response
The ECU will continue to operate normally.
0020-1
