Figure 6. Harness, Clamps, and Hardware Installation
CAB REAR WORK LIGHTS INTERIOR WIRING HARNESSES REPLACEMENT

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  85    86    87    88    89  90  91    92    93    94    95
. .
TM 5-3805-294-23-4
0500
HARNESS INSTALLATION - Continued
2
1
3
HYEX01669
Figure 8. Connect Harness To Right Cab Rear Work Light and Power Delivery Wiring Harness.
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Connect negative battery cable. (WP 0521)
2.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
0500-6
