TM 5-3805-294-23-4
0510
INSTALLATION - Continued
22.
Install bolt and clamp assembly (Figure 10, Item 10) and engine wiring harness (Figure 10, Item 5) to engine
(Figure 10, Item 6) with nut (Figure 10, Item 9).
23.
Connect engine wiring harness X01 (Figure 10, Item 7) to crankshaft position sensor (Figure 10, Item 8).
24.
Install bolt and clamp assembly (Figure 10, Item 4) and engine wiring harness (Figure 10, Item 5) to engine
(Figure 10, Item 6) with nut (Figure 10, Item 3).
25.
Connect engine wiring harness connector T04 (Figure 10, Item 1) to engine coolant temperature sensor (Figure
10, Item 2).
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Connect negative battery cable. (WP 0521)
2.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
0510-12
