TM 5-3805-294-23-4
FIELD MAINTENANCE
MACHINE WIRING HARNESS (W2) REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
Storage compartment lower access cover
(Volume 5, WP 0796, Table 2, Item 119)
removed. (WP 0610)
Hydraulic reservoir lower access cover removed.
Materials/Parts
Tags (Volume 5, WP 0797, Table 1, Item 52)
Pump compartment lower access cover removed.
Tie Wraps (Volume 5, WP 0797, Table 1, Item
56)
Engine compartment lower access cover removed.
Lockwasher (Volume 5, WP 0798, Table 1, Item
56) Qty: 2
Vandal protection kit removed from storage
compartment (TM 5-3805-294-10). (Volume 5,
WP 0794)
Personnel Required
Storage compartment forward access panel
Construction Equipment Repairer 91L (2)
removed. (WP 0609)
Center to cover removed. (WP 0589)
References
TM 5-3805-294-24P: Fig. 81 (Volume 5,
Time to Complete
WP 0794)
10.9 Hour(s)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Tag and mark wires, connectors, and wiring harnesses prior to removal to ensure proper
installation.
Note position of each tie wrap and remove as required.
0516-1
