TM 5-3805-294-23-4
0516
FOLLOW-ON MAINTENANCE - Continued
7.
Install storage compartment lower access cover. (WP 0610)
8.
Connect negative battery cable. (WP 0521)
9.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
0516-43/44 blank
