FOLLOW-ON MAINTENANCE - Continued
Figure 1. Bracket and Main Controller Removal

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  254    255    256    257    258  259  260    261    262    263    264
. . .
TM 5-3805-294-23-4
0517
FIELD MAINTENANCE
MAIN CONTROLLER REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
TM 5-3805-295-13&P (Volume 5, WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
(Volume 5, WP 0796, Table 2, Item 119)
WP 0794)
Materials/Parts
Tie Wraps (Volume 5, WP 0797, Table 1, Item
Equipment Condition
Machine safely parked and shut down
56)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Lockwasher (Volume 5, WP 0798, Table 1, Item
Negative battery cable disconnected. (WP 0521)
56) Qty: 4
Cab rear tray removed. (WP 0566)
Personnel Required
Construction Equipment Repairer 91L (1)
Time to Complete
1.6 Hour(s)
References
TM 5-3805-294-24P: Fig. 83, Fig. 84 (Volume 5,
WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Note position of each tie wrap and remove as required.
1.
Remove four bolts (Figure 1, Item 1) and washers (Figure 1, Item 2) from bracket (Figure 1, Item 3) and frame
(Figure 1, Item 4).
0517-1
