TM 5-3805-294-23-4
FIELD MAINTENANCE
AIR CONDITIONER BELT AND TENSIONER REPLACEMENT/ADJUSTMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Engine compartment lower access cover removed.
Tool Kit, General Mechanic's: Automotive (Volume
5, WP 0796, Table 2, Item 119)
Cooling compartment lower access cover
removed. (WP 0591)
Personnel Required
Construction Equipment Repairer 91L (1)
Time to Complete
0.5 Hour(s)
References
TM 5-3805-294-24P: Fig. 125 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
BELT REMOVAL
1.
Loosen tensioner pulley (Figure 1, Item 1).
0531-1
