TM 5-3805-294-23-4
0541
REMOVAL - Continued
1
3
2
HYEX02328
Figure 1. Resistor Removal
2.
Remove air conditioner/heater blower motor low speed resistor (Figure 1, Item 2) from air conditioner/heater
unit (Figure 1, Item 3).
END OF TASK
INSTALLATION
1.
Position air conditioner/heater blower motor low speed resistor (Figure 2, Item 2) to air conditioner/heater unit
(Figure 2, Item 3).
