TM 5-3805-294-23-4
FIELD MAINTENANCE
AIR CONDITIONER/HEATER BLOWER MOTOR REPLACEMENT
INITIAL SETUP:
Tools and Special Tools
Equipment Condition (cont.)
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0796, Table 2, Item 119)
Air conditioner refrigerant recovered. (WP 0540)
Seat belt removed. (WP 0579)
Seat removed. (WP 0580)
Materials/Parts
Cab rear tray removed. (WP 0566)
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
Cab rear wiring harness bracket removed.
34)
Lining (Volume 5, WP 0798, Table 1, Item 81)
Air conditioner/heater unit removed. (WP 0551)
Qty: 1
Time to Complete
Personnel Required
9.0 Hour(s)
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 122 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
0542-1
