TM 5-3805-294-23-4
0543
FIELD MAINTENANCE
AIR CONDITIONER/HEATER BLOWER MOTOR RESISTOR/THERMO FUSE REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Tool Kit, General Mechanic's: Automotive
WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
WP 0538
Materials/Parts
Seal (Volume 5, WP 0798, Table 1, Item 64)
Equipment Condition
Machine safely parked and shut down
Qty: 1
(TM 5-3805-294-10). (Volume 5, WP 0794)
Negative battery cable disconnected. (WP 0521)
Personnel Required
Seat belt removed. (WP 0579)
Construction Equipment Repairer 91L (1)
Seat removed. (WP 0580)
Cab rear tray and rear cover removed.
(WP 0566)
References
TM 5-3805-294-24P: Fig. 112, Fig. 122 (Volume 5,
WP 0794)
Time to Complete
4.1 Hour(s)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
1.
Remove bolt (Figure 1, Item 1) and washer (Figure 1, Item 2) from cover (Figure 1, Item 3) and rear wiring
harness bracket (Figure 1, Item 4).
0543-1
