TM 5-3805-294-23-4
FIELD MAINTENANCE
AIR CONDITIONER/HEATER CAB AIR TEMPERATURE SENSOR REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0796, Table 2, Item 119)
Seat belt removed. (WP 0579)
Seat removed. (WP 0580)
Cab rear tray and rear cover removed.
Personnel Required
Construction Equipment Repairer 91L (1)
Cab rear wiring harness bracket removed.
References
TM 5-3805-294-24P: Fig. 122 (Volume 5,
Time to Complete
WP 0794)
1.5 Hour(s)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
1.
Remove wiring harness connector B42 (Figure 1, Item 1) from air conditioner/heater cab air temperature sensor
connector (Figure 1, Item 2).
0545-1
