TM 5-3805-294-23-4
0544
INSTALLATION
1.
Install servo motor (Figure 2, Item 2) to air conditioner/heater unit (Figure 2, Item 4) with three screws (Figure
2, Item 3).
1
3
2
4
HYEX02338
Figure 2.
Servo Motor Installation.
2.
Install rod (Figure 2, Item 1) to servo motor (Figure 2, Item 2).
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Install air conditioner/heater unit. (WP 0551)
2.
Install cab rear wiring harness bracket. (WP 0572)
3.
Install cab rear tray and rear cover. (WP 0566)
4.
Install seat. (WP 0580)
5.
Install seat belt. (WP 0579)
6.
Replace receiver dryer. (WP 0538)
7.
Connect negative battery cable. (WP 0521)
8.
Service air conditioner refrigerant. (WP 0540)
9.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
