TM 5-3805-294-23-4
0571
RIGHT, REAR, AND LEFT CAB WINDOWPANES INSTALLATION - Continued
11
12
10
HYEX02809
Figure 4.
Windowpane Locations.
NOTE
Only perform Step (1) if replacing left cab windowpane.
1.
Remove bushing (Figure 5, Item 15) from left cab windowpane (Figure 5, Item 10).
