TM 5-3805-294-23-4
FIELD MAINTENANCE
WINDSHIELD WASHER REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
TM 5-3805-295-13&P (Volume 5, WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
(Volume 5, WP 0796, Table 2, Item 119)
WP 0794)
Pan, Drain (Volume 5, WP 0796, Table 2, Item
55)
Equipment Condition
Machine safely parked and shut down
Materials/Parts
(TM 5-3805-294-10). (Volume 5, WP 0794)
Tags (Volume 5, WP 0797, Table 1, Item 52)
Negative battery cable disconnected. (WP 0521)
Screw (Volume 5, WP 0798, Table 1, Item 78)
Qty: 1
Time to Complete
0.7 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 100, Fig. 114 (Volume 5,
WP 0794)
RESERVOIR AND PUMP REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
If HYEX is equipped with a Supplemental Armor Set, refer to and use procedure found in TM
5-3805-295-13&P.
1.
Disconnect machine wiring harness connector M6 (Figure 1, Item 1) from pump (Figure 1, Item 2).
0584-1
