Figure 4. Valve Mount Plate Installation.
HYDRAULIC PUMP COMPARTMENT DOOR LATCH, AND ISOLATOR REPLACEMENT

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  789    790    791    792    793  794  795    796    797    798    799
.
TM 5-3805-294-23-4
0597
FOLLOW ON MAINTENANCE
1.
Install deep dig attachment pattern change switch. (Volume 5, WP 0678)
2.
Install hydraulic hose reel selector switch. (Volume 5, WP 0694)
3.
Install storage compartment forward access panel. (WP 0609)
4.
Install hydraulic hose reel. (Volume 5, WP 0693)
5.
Install air cleaner. (Volume 3, WP 0456)
6.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
0597-6
