TM 5-3805-294-23-4
FIELD MAINTENANCE
STORAGE COMPARTMENT COVER REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
TM 5-3805-295-13&P (Volume 5, WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
(Volume 5, WP 0796, Table 2, Item 119)
WP 0794)
Cap and Plug Set (Volume 5, WP 0796, Table 2,
Item 55)
Equipment Condition
Machine safely parked and shut down
Materials/Parts
Sealing Compound, Thread Lock
(TM 5-3805-294-10). (Volume 5, WP 0794)
(Volume 5, WP 0797, Table 1, Item 43)
Engine cover removed. (WP 0594)
Locknut (Volume 5, WP 0798, Table 1, Item 30)
Center top cover removed. (WP 0589)
Engine compartment lower access cover removed.
Qty: 2
Personnel Required
Construction Equipment Repairer 91L (2)
Time to Complete
2.2 Hour(s)
References
TM 5-3805-294-24P: Fig. 61, Fig. 62, Fig. 130, Fig.
211 (Volume 5, WP 0794)
REMOVAL
WARNING
Use extreme care when removing radiator cap. If time permits, allow engine to cool before
opening cooling system. When engine is hot, there is pressure in the cooling system. Sudden
release of pressure can cause a steam flash. Wear protective goggles and use a clean, thick
waste cloth or like material to aid in removing the radiator cap. Avoid using gloves because
they can become soaked with hot water. Slowly loosen radiator cap to the first stop to relieve
pressure before removing radiator cap completely. Failure to comply may result in injury or
death to personnel.
NOTE
If HYEX is equipped with a Supplemental Armor Set, remove and install CCTV Conduit using
procedure found in TM 5-3805-295-13&P.
1.
Remove cap (Figure 1, Item 1) from coolant surge tank (Figure 1, Item 2).
