TM 5-3805-294-23-4
0626
FIELD MAINTENANCE
ARM LINKS AND PINS REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
TM 5-3805-294-24P: Fig. 163, Fig. 164 (Volume 5,
Tool Kit, General Mechanic's: Automotive
WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Lifting Device, Minimum Capacity 500 lb
Wrench, Torque, 90-600 lb-ft (122-813 Nm), 3/4 in.
WP 0794)
Drive (Volume 5, WP 0796, Table 2, Item
130)
Equipment Condition
Machine safely parked and shut down
Materials/Parts
(TM 5-3805-294-10). (Volume 5, WP 0794)
Grease, Automotive and Artillery, GAA
(Volume 5, WP 0797, Table 1, Item 11)
Time to Complete
Wood Block Qty: 1
2.0 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (2)
References
TM 5-3805-294-10 (Volume 5, WP 0794)
ARM LINKS AND PINS REMOVAL
NOTE
It is not necessary to remove bucket to accomplish this task.
Note location and quantity of shims prior to removal to ensure proper installation.
1.
Remove two nuts (Figure 1, Item 1) from bolt (Figure 1, Item 2).
0626-1
