TM 5-3805-294-23-1
0018
Table 1. DTC 97.03 - Water in Fuel Signal Out of Range High - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Replace sockets in engine
17.
Engine Interface
interface wiring harness
Wiring Harness
connector D01 (Volume 4,
Connector D01
Sockets and WIF
WP 0511) or replace engine
Sensor Are Faulty.
interface wiring harness.
(Volume 4, WP 0509)
2.
Replace WIF sensor. (Volume
3, WP 0454)
3.
Turn key switch to ON position,
but DO NOT START ENGINE
(TM 5-3805-294-10). (Volume
5, WP 0794)
4.
Clear and refresh DTCs. Note
if DTC 97.03 is still active
DTC. (Volume 3, WP 0362)
5.
Turn key switch to OFF
1.
If DTC 97.03 is still active, it is
position (TM 5-3805-294-10).
possible that another fault
exists or that another
(Volume 5, WP 0794)
troubleshooting procedure
applies. If this was the first time
through this procedure, restart
procedure at Malfunction 1.
If DTC 97.03 is not active,
2.
problem corrected.
END OF WORK PACKAGE
0018-10
