TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 97.04 - WATER IN FUEL SIGNAL OUT OF RANGE LOW
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0345
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0362
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0363
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0369
Multimeter, Digital
Volume 3, WP 0454
(Volume 5, WP 0796, Table 2, Item 77)
Volume 4, WP 0508
Probe Set, Standard
Volume 4, WP 0509
(Volume 5, WP 0796, Table 2, Item 91)
Volume 4, WP 0510
Test Set, MSD Electronic Systems
Volume 4, WP 0511
(Volume 5, WP 0796, Table 2, Item 116)
Volume 5, WP 0800
Personnel Required
Equipment Condition
Construction Equipment Repairer 91L (2)
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
Test Equipment Setup for MSD and Service
References
ADVISOR. (Volume 3, WP 0375)
TM 5-3805-294-10 (Volume 5, WP 0794)
Troubleshooting Sequence
DTC 97.04
When DTC is Displayed
Whenever the ignition is on and the error is active.
Related Information
The water in fuel voltage drops below the minimum threshold. The voltage is lower than what is physically possible
for the water in fuel sensor to achieve.
Alarm Level
Warning.
Control Unit Response
The ECU will continue to operate normally.
0019-1
