TM 5-3805-294-23-1
FIELD MAINTENANCE
ENGINE CRANKS/WILL NOT START
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0328
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0334
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0345
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0362
Multimeter, Digital
Volume 3, WP 0363
(Volume 5, WP 0796, Table 2, Item 77)
Volume 3, WP 0364
Probe Set, Standard
Volume 3, WP 0369
(Volume 5, WP 0796, Table 2, Item 91)
Volume 3, WP 0407
Test Set, MSD Electronic Systems
Volume 3, WP 0410
(Volume 5, WP 0796, Table 2, Item 116)
Volume 3, WP 0414
Volume 3, WP 0444
Volume 3, WP 0453
Personnel Required
Volume 3, WP 0456
Construction Equipment Repairer 91L (2)
Volume 3, WP 0482
Volume 4, WP 0496
References
Volume 4, WP 0508
TM 5-3805-294-10 (Volume 5, WP 0794)
Volume 5, WP 0800
Equipment Condition
Machine safely parked and shut down (TM
5-3805-294-10). (Volume 5, WP 0794)
Test Equipment Setup for MSD and Service
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0321
TROUBLESHOOTING PROCEDURE
Table 1. Engine Cranks/Will Not Start.
Test or Inspection
Corrective Action
Malfunction
Visually inspect fuel shutoff
1.
If valve is open, proceed to
1.
valve to determine if valve is
Malfunction 2.
Closed.
open. (Volume 5, WP 0800,
2.
If valve is closed, open valve.
Figure 228)
(Volume 5, WP 0800, Figure
228)
1.
Turn key switch to ON position,
2.
Fuel Level Low.
but DO NOT START ENGINE
(TM 5-3805-294-10). (Volume
5, WP 0794)
0115-1
