TM 5-3805-294-23-4
0507
FIELD MAINTENANCE
CRUSH-ALL MAIN BODY AND BOOM WIRING HARNESS REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0796, Table 2, Item 119)
Center top cover removed. (WP 0589)
Materials/Parts
Time to Complete
Tags (Volume 5, WP 0797, Table 1, Item 52)
1.2 Hour(s)
Tie Wraps (Volume 5, WP 0797, Table 1, Item
56)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 90 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
CRUSH-ALL MAIN BODY WIRING HARNESS REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Tag and mark wires, connectors, and wiring harnesses prior to removal to ensure proper
installation.
Note position of each tie wrap and remove as required.
Crush-all main body wiring harness is routed along with the machine wiring harness (W2)
from behind cab to the inside of the main frame.
0507-1
