TM 5-3805-294-23-4
0513
FIELD MAINTENANCE
INFORMATION CONTROLLER REPLACEMENT
INITIAL SETUP:
References
Tools and Special Tools
TM 5-3805-294-24P: Fig. 83 (Volume 5,
Tool Kit, General Mechanic's: Automotive (Volume
WP 0794)
5, WP 0796, Table 2, Item 119)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Materials/Parts
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
34)
Equipment Condition
Machine safely parked and shut down
Tie Wraps (Volume 5, WP 0797, Table 1, Item
(TM 5-3805-294-10). (Volume 5, WP 0794)
56)
Negative battery cable disconnected. (WP 0521)
Lockwasher (Volume 5, WP 0798, Table 1, Item
Cab rear tray removed. (WP 0566)
56) Qty: 3
Time to Complete
Personnel Required
Construction Equipment Repairer 91L (1)
1.5 Hour(s)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Note position of each tie wrap and remove as required.
1.
Disconnect cab wiring harness W1 connectors X32 (Figure 1, Item 1) and X34 (Figure 1, Item 2) from
information controller (Figure 1, Item 3).
0513-1
