TM 5-3805-294-23-4
0539
FIELD MAINTENANCE
AIR CONDITIONER RECEIVER-DRYER TO EVAPORATOR HOSE REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Tool Kit, Refrigeration
WP 0794)
(Volume 5, WP 0796, Table 2, Item 120)
WP 0538
WP 0566
Materials/Parts
WP 0588
Lubricating Oil, Refrigerant Compressor (Volume
WP 0610
5, WP 0797, Table 1, Item 27)
WP 0591
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
34)
Tie Wraps (Volume 5, WP 0797, Table 1, Item
Equipment Condition
56)
Machine safely parked and shut down
O-ring (Volume 5, WP 0798, Table 1, Item 60)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Qty: 2
Air conditioner refrigerant recovered. (WP 0540)
O-ring (Volume 5, WP 0798, Table 1, Item 61)
Cooling compartment lower access cover
Qty: 2
removed. (WP 0591)
Storage compartment lower access cover
removed. (WP 0610)
Personnel Required
Cab rear lower armor plate removed. (WP 0588)
Utilities Equipment Repairer 91C (1)
Cab rear tray and cover removed. (WP 0566)
References
Time to Complete
TM 5-3805-294-24P: Fig. 112, Fig. 124 (Volume 5,
4.5 Hour(s)
WP 0794)
REMOVAL
NOTE
Note position of each tie wrap and remove as required.
Note routing of hose during removal to ensure proper installation.
1.
Remove bolt (Figure 1, Item 1), washer (Figure 1, Item 2), hose (Figure 1, Item 3), and O-ring (Figure 1, Item
4) from receiver-dryer (Figure 1, Item 5).
0539-1
