TM 5-3805-294-23-4
0567
REMOVAL - Continued
106
104, 105
9
HYEX02835
Figure 16. Air Duct Removal.
NOTE
Some parts shown removed for clarity.
44.
Remove three bolts (Figure 17, Item 107), washers (Figure 17, Item 108), and cab mount (Figure 17, Item 109)
from cab (Figure 17, Item 9).
