TM 5-3805-294-23-4
0574
REMOVAL - Continued
7
6
5
HYEX01165
Figure 3. Wiper Motor Cover Removal.
5.
Remove electrical connector (Figure 4, Item 8) from receptacle (Figure 4, Item 9).
9
8
HYEX01166
Figure 4. Electrical Connector Removal.
6.
Remove two bolts (Figure 5, Item 10) and wiper motor (Figure 5, Item 7) from operator cab frame (Figure 5,
Item 11). Discard bolts.
