TM 5-3805-294-23-4
0577
INSTALLATION
6.
Install clamp mount (Figure 10, Item 3) and clamp plate (Figure 10, Item 4) to guard bars (Figure 10, Item 5)
with two hand knobs (Figure 10, Item 1) and washers (Figure 10, Item 2).
5
5
2
1
4
3
HYEX01170
Figure 10.
Rifle Clamp Mount and Clamp Plate Installation.
END OF TASK
FOLLOW-ON MAINTENANCE
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
