TM 5-3805-294-23-4
0580
INSTALLATION - Continued
16
15
6
HYEX00835
Figure 6. Seat Installation.
2.
Tighten screws (Figure 6, Item 15) to 30 lb-ft (40 Nm).
3.
Push lever (Figure 7, Item 7) down and move seat stand (Figure 7, Item 6) forward until it stops.
