TM 5-3805-294-23-4
FIELD MAINTENANCE
SEAT STAND AND SUPPORTS REPLACEMENT
INITIAL SETUP:
Tools and Special Tools
References (cont.)
Tool Kit, General Mechanic's: Automotive
DA FORM 5988-E or DA FORM 2404 (Volume 5,
(Volume 5, WP 0796, Table 2, Item 119)
WP 0794)
Wrench, Torque, 90-600 lb-ft (122-813 Nm), 3/4 in.
Drive (Volume 5, WP 0796, Table 2, Item
130)
Equipment Condition
Machine safely parked and shut down
Materials/Parts
(TM 5-3805-294-10). (Volume 5, WP 0794)
Lockwasher (Volume 5, WP 0798, Table 1, Item
Seat belt removed. (WP 0579)
56) Qty: 7
Seat removed. (WP 0580)
Lockwasher (Volume 5, WP 0798, Table 1, Item
35) Qty: 8
Time to Complete
3.9 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (2)
References
TM 5-3805-294-24P: Fig. 118 (Volume 5,
WP 0794)
SEAT STAND REMOVAL
1.
Remove two caps (Figure 1, Item 1) from cover (Figure 1, Item 2).
0581-1
