TM 5-3805-294-23-4
0629
INSTALLATION - Continued
51, 52, 53
54
50
14
HYEX02280
Figure 38. Solenoid Valve Assembly Installation.
21.
Install wire connector (49) to solenoid valve (50) with screw (48).
50
48
49
HYEX02279
Figure 39. Solenoid Valve Connector Installation.
22.
Install hose (19) to fitting (47).
