TM 5-3805-294-23-4
0629
INSTALLATION - Continued
3
14
21
HYEX02271
Figure 44. Secure Bucket Cylinder.
30.
Secure bucket cylinder (3) to arm (14).
31.
Remove suitable lifting device (25) from bucket cylinder (3).
3
25
HYEX02275
Figure 45.
Lifting Device Removal .
32.
Install hose (40) to fitting (41).
