TM 5-3805-294-23-4
FIELD MAINTENANCE
BUCKET FLOW RATE CONTROL VALVE REPLACEMENT
INITIAL SETUP:
References
Tools and Special Tools
TM 5-3805-294-24P: Fig. 176 (Volume 5,
Tool Kit, General Mechanic's: Automotive
WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Gloves, Rubber (Volume 5, WP 0796, Table 2,
WP 0794)
Item 55)
Goggles, Industrial (Volume 5, WP 0796, Table 2,
Item 58)
Equipment Condition
Pan, Drain (Volume 5, WP 0796, Table 2, Item
Machine safely parked and shut down
55)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Hydraulic system pressure relieved. (Volume 5,
WP 0767)
Materials/Parts
Lubricating Oil, Engine OE/HDO 15W-40
Center top cover removed. (WP 0589)
(Volume 5, WP 0797, Table 1, Item 18)
O-ring (Volume 5, WP 0798, Table 1, Item 105)
Time to Complete
Qty: 1
1.5 Hour(s)
O-ring (Volume 5, WP 0798, Table 1, Item 66)
Qty: 1
Personnel Required
Construction Equipment Repairer 91L (1)
REMOVAL
WARNING
WARNING
Hydraulic system operates at high pressures and temperatures. Always allow hydraulic oil to
cool and relieve pressure in hydraulic reservoir before working on hydraulic system. Wear
eye protection and gloves to prevent injury. Open lines and hoses slowly and wait for any
residual pressure to relieve before continuing to open lines and hoses. Failure to comply may
result in injury or death to personnel.
0657-1
