TM 5-3805-294-23-4
0535
INSTALLATION - Continued
10.
Install freeze switch connector (Figure 5, Item 2) to evaporator cover (Figure 5, Item 3).
1
2
3
HYEX02186
Figure 6.
Remove Wiring.
11.
Install right-hand console wiring harness W11 connector B41 (Figure 5, Item 1) to freeze switch connector
(Figure 5, Item 2).
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Install cab rear wiring harness bracket. (WP 0572)
2.
Install cab rear tray and cover. (WP 0566)
3.
Install seat. (WP 0580)
4.
Replace receiver dryer. (WP 0538)
5.
Connect negative battery cable. (WP 0521)
6.
Service air conditioner refrigerant. (WP 0540)
7.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
