TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB RIGHT-HAND CONSOLE COVERS REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
TM 5-3805-294-24P: Fig. 107 (Volume 5,
Tool Kit, General Mechanic's: Automotive
WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Materials/Parts
Lockwasher (Volume 5, WP 0798, Table 1, Item
Equipment Condition
56) Qty: 11
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
Personnel Required
Negative battery cable disconnected. (WP 0521)
Construction Equipment Repairer 91L (1)
Time to Complete
References
0.5 Hour(s)
TM 5-3805-294-10 (Volume 5, WP 0794)
UPPER COVERS REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Adjust seat assembly as necessary to access the right-hand console (TM
5-3805-294-10). (Volume 5, WP 0794)
Note position of boot prior to removal to ensure proper installation.
1.
Remove two screws (Figure 1, Item 1), lockwashers (Figure 1, Item 2), washers (Figure 1, Item 3), and bracket
(Figure 1, Item 4) from cover (Figure 1, Item 5). Discard lockwashers.
0568-1
