TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB SKYLIGHT WINDOW AND SEAL REPLACEMENT
INITIAL SETUP:
Materials/Parts (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Packing (Volume 5, WP 0798, Table 1, Item 58)
(Volume 5, WP 0796, Table 2, Item 119)
Qty: 2
Seal (Volume 5, WP 0798, Table 1, Item 88)
Qty: 1
Materials/Parts
Sealing Compound
(Volume 5, WP 0797, Table 1, Item 40)
Personnel Required
Screw, Cap, Hex (Volume 5, WP 0798, Table 1,
Construction Equipment Repairer 91L (1)
Item 89) Qty: 4
Bolt, Machine (Volume 5, WP 0798, Table 1, Item
References
84) Qty: 4
TM 5-3805-294-24P: Fig. 103 (Volume 5,
Packing (Volume 5, WP 0798, Table 1, Item 65)
WP 0794)
Qty: 4
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Packing (Volume 5, WP 0798, Table 1, Item 83)
WP 0794)
Qty: 12
Screw, Cap, Hex (Volume 5, WP 0798, Table 1,
Item 85) Qty: 2
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
Time to Complete
0.4 Hour(s)
CAB SKYLIGHT WINDOW REMOVAL
WARNING
Replace broken window glass carefully. Wear a pair of heavy leather gloves or other suitable
hand protection. Support window glass during removal and installation, as required, so it does
not drop. Failure to comply may result in serious injury or death to personnel.
NOTE
The parts that are replaced in this procedure will not be found on a HYEX that has the
Supplemental Armor System (SAS) cab installed.
1.
Remove four cotter pins (Figure 1, Item 1) and two cylinders (Figure 1, Item 2) from skylight window (Figure
1, Item 3) and cab (Figure 1, Item 4).
