TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB RIGHT-HAND CONSOLE REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0796, Table 2, Item 119)
Seat removed. (WP 0580)
Right-hand armrest removed. (WP 0553)
Right-hand pilot control valve lever removed.
Personnel Required
(Volume 5, WP 0768)
Construction Equipment Repairer 91L (1)
Cab right-hand console covers removed.
Radio removed. (WP 0616)
References
Air conditioner/heater controller removed.
TM 5-3805-294-24P: Fig. 106, Fig. 156 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Time to Complete
5.4 Hour(s)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
NOTE
Note position of screw and spring pin prior to removal to ensure proper installation.
0569-1
