TM 5-3805-294-23-4
0575
INSTALLATION - Continued
8
7
6
5
HYEX01651
Figure 10.
Electrical Connector Installation.
6.
Install two side covers (Figure 11, Item 2) to front cover (Figure 11, Item 3) and cover (Figure 11, Item 4) with
six clips (Figure 11, Item 1).
3
1
2
4
HYEX01653
Figure 11.
Headliner Side Cover Installation.
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Connect negative battery cable. (WP 0521)
2.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
