Figure 18. Rear Seat Stand Support Installation.
Figure 20. Bracket Screw Installation.

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  703    704    705    706    707  708  709    710    711    712    713
.
TM 5-3805-294-23-4
0581
SUPPORT INSTALLATION - Continued
14
30
31
27
29
28
HYEX02035
Figure 19. Bracket Installation.
9.
Install screw (Figure 19, Item 28) and washer (Figure 19, Item 29) to bracket (Figure 19, Item 27).
10.
Install screw (Figure 20, Item 25) and washer (Figure 20, Item 26) to bracket (Figure 20, Item 27).
0581-18
