TM 5-3805-294-23-4
FIELD MAINTENANCE
ARM REDUCED LEAKAGE VALVES REPLACEMENT
INITIAL SETUP:
Materials/Parts (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
O-ring (Volume 5, WP 0798, Table 1, Item 52)
(Volume 5, WP 0796, Table 2, Item 119)
Qty: 1
Gloves, Rubber (Volume 5, WP 0796, Table 2,
O-ring (Volume 5, WP 0798, Table 1, Item 105)
Item 55)
Qty: 1
Goggles, Industrial (Volume 5, WP 0796, Table 2,
Item 58)
Personnel Required
Pan, Drain (Volume 5, WP 0796, Table 2, Item
Construction Equipment Repairer 91L (1)
55)
References
Materials/Parts
TM 5-3805-294-24P: Fig. 175, Fig. 176, Fig. 177
Lubricating Oil, Engine OE/HDO 15W-40
(Volume 5, WP 0794)
(Volume 5, WP 0797, Table 1, Item 18)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
O-ring (Volume 5, WP 0798, Table 1, Item 66)
WP 0794)
Qty: 7
O-ring (Volume 5, WP 0798, Table 1, Item 92)
Qty: 1
Equipment Condition
O-ring (Volume 5, WP 0798, Table 1, Item 129)
Machine safely parked and shut down
Qty: 1
(TM 5-3805-294-10). (Volume 5, WP 0794)
Hydraulic system pressure relieved. (Volume 5,
WP 0767)
Vacuum applied to hydraulic reservoir. (WP 0620)
Center top cover removed. (WP 0589)
Time to Complete
1.5 Hour(s)
ARM REDUCED LEAKAGE VALVES REMOVAL
WARNING
0627-1
