Figure 2. Auxiliary Control Switch And Wiring Harness Installation
Figure 2. Auxiliary Control Wiring Harness (W15) Connection B and C Disconnect

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  20    21    22    23    24  25  26    27    28    29    30
. . . . .
TM 5-3805-294-23-4
0492
FIELD MAINTENANCE
AUXILIARY CONTROL WIRING HARNESS (W15) REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0796, Table 2, Item 119)
Seat removed. (WP 0580)
Cab rear tray removed. (WP 0566)
Storage compartment forward access panel
Materials/Parts
removed. (WP 0609)
Tie Wraps (Volume 5, WP 0797, Table 1, Item
56)
Lockwasher (Volume 5, WP 0798, Table 1, Item
Time to Complete
56) Qty: 1
5.0 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 81, Fig. 83, Fig. 85, Fig.
86 (Volume 5, WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Note position of each tie wrap and remove as required.
1.
Disconnect auxiliary control wiring harness (W15) at connection SR/H Y34 (Figure 1, Item 1) from crush-all
main body harness (Figure 1, Item 2).
0492-1
